Name: Screw Thread Rolling Die with High Wear-resistance Quality
Brand: Dongguan Fanchi Mold Technology Co., Ltd
SKU: Customized
Price: 60.00 USD
Availability: InStock

Home > products > Thread Rolling Dies >

Screw Thread Rolling Die with High Wear-resistance Quality

odm thread rolling dies

oem thread rolling dies

odm thread rolling machine dies

Place of Origin:

Chongqing, China

Brand Name:

Henghui

Model Number:

Customized

Request A Quote

Screw Thread Rolling Die with High Wear-resistance Quality

Product Details

Shaping Mode:

Forging Mould

Product Material:

Steel

Product:

Vehicle Mould

Product Name:

Screw Thread Rolling Die

Material:

,DC53

Application:

Screw Making

Design Software:

CAD

Size:

Customized Size

MOQ:

1 Set

Hardness:

Normal From 60 HRC To 64 HRC

Packaging:

Standard Package

Service:

OEM\ODM

Drawing Format:

2D/(PDF/CAD)3D(IGES/STEP)

Port:

Chongqing, Shanghai, Shenzhen Or As Client's Need

Name:

Thread Rolling Dies

Highlight:

odm thread rolling dies

oem thread rolling dies

odm thread rolling machine dies

Payment & Shipping Terms

Price

$20.00 - $100.00/sets

Packaging Details

export standard wooden box, or as client's requirement.

Supply Ability

2000 Set/Sets per Month

2023 Customized DC53 H9+N Hot Sales Screw Die Of Flat Thread Rolling Dies

Get Best Price

Video

Top Hot Sales Products Thread Rolling Plate Screw Thread Rolling Dies

Get Best Price

Video

Henghui Forging Mould Shaping Product Thread Rolling Dies For Making Drywall Screw

Get Best Price

Video

DC53 High Quality Drywall Screw ,Chipboard Screw Thread Rolling Die

Get Best Price

Contact Now

Product Description

Products Description

Material:

Our main case material are DC53+N or H9+N

Size:

Length*Height*thickness(for example, 90/105x25x25mm)

DC53：

Chemical Composition	C	Si	Mn	P	S	Cr	Mo	V	W
Content (%)	0.95	0.89	0.3	0.018	0.006	7.7	1.92	0.75	0.91

MACHINE TYPE	s	H	L1(FIXED)	L2(MOVING)
0	19	25	51	64
3/16	25	25,38, 55	75	90
1/4	25	25,40, 55, 65,80	100	115
5/16	25	25,40, 55, 65,80, 105	127	140
3/8	25	25,40, 55, 65,80, 105	150	165
1/2	35	55, 80, 105, 125,150	190	215
3/4	38	55, 80, 105,125,150	230	265
003	15	20	45	55
004	20	25	65	80
4R	20	25	60	70
6R	25	25, 30, 40, 55	90	105
8R	25	25, 30, 40, 55, 65	108	127
250	25	25, 40, 55	110	125
DR125	20.8	25, 40	73.3	86.2 (5。）
DR200	20.8	25, 40, 53	92.3	105.2 (53)
DR250	23.8	25, 40, 54	112	131.2 (Í)

* Long life of the thread rolling die

Henghui is specialized in the making of screw thread rolling dies, made of best raw materials available in the market. These screw thread rolling dies are designed professionally by our engineers per customers’ specifications or work pieces. Each staff tries try his best to have screw thread rolling dies with high accuracy, high strength and high stability by high skills and strict quality control system.Therefore the screw thread rolling dies life is longer than dies produced by other companies based on the same materials and the same price or even lower price.
Henghui manufacture thread rolling dies taking the needs of our customers very much into account. The range of thread rolling dies covers most of threading machines on the market. Likewise, we cover all kinds of screw threads.
We also manufacture custom thread rolling dies to customer specifications. You can see examples of different designs and shapes in the product details page.
Furthermore, we advise our customers in choosing the type of thread rolling die that best suits their needs. You can send your technical inquiries to us, and we will be in touch within 24 hours to offer you the best solution.

Process
